KV222-418
click: 3693
Compact connector 5 line with lever maximum continuous working temperature of 85 ° CRoHS compliantThe project team7 (Installation technology)Minimum sectional area of connectable wire [mm?]0,08 - 2,5 mm?Minimum sectional area of connectable wire [AW
pdf download：click down
Detailed description
- technical
- Dimension
- Ordering
- Related
| Compact connector 5 line with lever maximum continuous working temperature of 85 ° C | ||
| RoHS compliant | ||
| The project team | 7 (Installation technology) |
| Minimum sectional area of connectable wire [mm?] | 0,08 - 2,5 mm? |
| Minimum sectional area of connectable wire [AWG] | 28 - 14 AWG |
| Applicable conductor type | e+f |
| The connection method | CAGE CLAMP?CONNECTION |
| Minimum sectional area of connectable wire [mm?] | 0,08 - 4 mm? |
| Minimum sectional area of connectable wire [AWG] | 28 - 12 AWG |
| Applicable conductor type | f |
| The rated voltage EN | 400 V |
| Can withstand instantaneous peak voltage | 4 kV |
| Pollution levels | 2 |
| Rated current EN | 32 A |
| The rated voltage EN | 600 V |
| Rated current EN | 20 A |
| Weight | 6,6 g |
| color | grey |
| Wiring direction | Lateral connection |
| Number of connectable wires | 5 |
| Number of potential | 1 |
| height | 14,5 mm |
| height | |
| thickness | 21?mm |
| thickness | |
| width | 40.3?mm |
| width | |
| Minimum stripping length | 9 mm |
| Maximum stripping length | 10 mm |
| Wire stripping length | 0,37 in |
